GMM-ARB150-DMAX
The GreenMech Arborist 150D is a proven, professional wood chipper with a 6 inch / 150mm capacity, widely regarded as one of the most successful machines in its class. Powered by a 25hp Kubota diesel engine, it’s built to deliver dependable, high-output chipping while setting the benchmark for quiet running, durability and long-term performance.
A generous in-feed hopper makes handling bulky material easier, while hydraulically powered feed rollers pull brash through consistently with minimal effort from the operator. The electronically controlled No-Stress system helps maintain rotor speed under load for smoother throughput, and the renowned Disc-Blade system extends sharpening intervals and reduces downtime, keeping you productive day after day.
-
150mm (6 inch) chipping capacity for serious site work
-
25hp Kubota diesel engine delivering reliable professional performance
-
No-Stress in-feed + hydraulic feed rollers for smooth, controlled throughput
-
Disc-Blade system for longer blade life, less downtime and easier maintenance
Need Some Advice?
Technical Specifications
|
CAPACITY |
150mm |
|
ENGINE MAKE |
Kubota D 1105 |
|
ENGINE OUTPUT |
25hp |
|
FUEL |
Diesel |
|
CHIPPING FLYWHEEL |
Disc Type |
|
BLADES |
4 |
|
HYDRAULIC FEED ROLLERS |
Twin Vertical |
|
POWER CONTROL |
No Stress |
|
FUEL CAPACITY (ENGINE) |
27 Litres |
|
HYDRAULIC OIL CAPACITY |
30 Litres |
|
SPARE WHEEL |
N/A |
|
TONNES PER HOUR |
13 Cubic Metres / 3.75 Tonnes Per Hour |
|
INFEED CHUTE APERTURE |
970mm x 790mm |
|
INFEED THROAT SIZE |
150mm x 230mm |
|
DISCHARGE CHUTE |
280 Degrees Rotation |
|
HOUR METER |
Standard |
|
LENGTH (TRANSPORT) |
3556mm |
|
WIDTH (TRANSPORT) |
1290mm |
|
HEIGHT (DISCHARGE CHUTE UP) |
2335mm |
|
WEIGHT |
750 kg |
|
SOUND POWER LWA |
115 dB(A) |
|
SOUND PRESSURE LPA |
92 dB(A) |
