GMM-QUADTRAK-160
The GreenMech QuadTrak 160D is a specialist tracked chipper built for roadside and highway maintenance. The whole chipper unit swivels 270°, letting operators feed safely away from live traffic. Powered by a 25hp Kubota diesel engine, it’s designed to work confidently on banks and cuttings thanks to a tilting track underbelly (up to 30°). A strong high-tensile steel chassis, generous hopper, twin vertical rollers and electronic No-Stress control keep material flowing efficiently, while GreenMech’s Disc-Blade system reduces sharpening intervals and downtime. It’s supplied with an integrated trailer for straightforward transport and loading, and can even be operated while still mounted.
-
270° swivel chassis positions the in-feed away from the roadside for safer operation
-
Tilting track underbelly (up to 30°) for banks, side-lands and cuttings
-
25hp Kubota diesel + electronic No-Stress feed for steady, efficient throughput
-
Disc-Blade system with long sharpening intervals (approx. 150 hours) to cut downtime
Need Some Advice?
Technical Specifications
| CAPACITY | 160mm |
| ENGINE MAKE | Kubota |
| ENGINE OUTPUT | 25hp |
| FUEL | Diesel |
| TURNTABLE | 270˚ locking at 45˚ increments |
| GROUND CLEARANCE | 240mm |
| TRACK SPEED | 3kph |
| CHIPPING FLYWHEEL | Disc Type |
| BLADES | 4 |
| HYDRAULIC FEED ROLLERS | Twin Horizontal |
| POWER CONTROL | No Stress |
| FUEL CAPACITY (ENGINE) | 32 Litres |
| HYDRAULIC OIL CAPACITY | 32 Litres |
| SPARE WHEEL | N/A |
| TONNES PER HOUR | 11 Cubic Metres / 3.5 Tonnes Per Hour |
| INFEED CHUTE APERTURE | 1100mm x 800mm |
| INFEED THROAT SIZE | 160mm x 230mm |
| DISCHARGE CHUTE | 280 Degrees Rotation |
| HOUR METER | Standard |
| LENGTH (TRANSPORT) | 2368mm |
| WIDTH (TRANSPORT) | 1366mm |
| HEIGHT (DISCHARGE CHUTE UP) | 2487mm |
| CRAWLER / TRACK DRIVE (L x W x H) | 1447mm (1146mm) x 230mm x 306mm |
| CRAWLER / TRACK DRIVE (WIDTH) | Outside: 1171mm / Inside: 711mm |
| WEIGHT | 1100 kg |
| SOUND POWER LWA | 116 dB(A) |
| SOUND PRESSURE LPA | 92 dB(A) |
