GMM-QUADCHIP
Out of stock
SKU
GMM-QUADCHIP
The EVO 205D takes chipping to the next level with EVEN More Torque, Bite, and Throughput. Powered by a 50hp Kubota Stage V diesel engine, it features a robust steel chassis, a large 1250mm x 700mm in-feed hopper, and GreenMech’s Disc Blade System for extended sharpening intervals.
The Smart Sense No-Stress system optimizes material flow for maximum efficiency. With minimal maintenance needs, a hinged steel bonnet, and a 3-year unlimited warranty, the EVO 205D is built to perform with long-lasting value.
Top Features
-
50hp Kubota diesel engine
-
1250mm x 700mm in-feed hopper
-
Disc Blade System with 150-hour sharpening intervals
-
Smart Sense No-Stress system for optimized throughput
Need Some Advice?
Technical Specifications
| CAPACITY | 160mm |
| ENGINE MAKE | Vanguard |
| ENGINE OUTPUT |
40hp |
| FUEL | Petrol |
| TURNTABLE | 360˚ locking at 45˚ increments |
| CHIPPING FLYWHEEL | Disc Type |
| BLADES | 4 |
| HYDRAULIC FEED ROLLERS | Twin Horizontal |
| POWER CONTROL | No Stress |
| FUEL CAPACITY (ENGINE) | 32 Litres |
| HYDRAULIC OIL CAPACITY | 32 Litres |
| SPARE WHEEL | N/A |
| TONNES PER HOUR | 11 Cubic Metres / 3.5 Tonnes Per Hour |
| INFEED CHUTE APERTURE | 1100mm x 800mm |
| INFEED THROAT SIZE | 160mm x 230mm |
| DISCHARGE CHUTE | 280 Degrees Rotation |
| HOUR METER | Standard |
| LENGTH (TRANSPORT) | 3211mm |
| WIDTH (TRANSPORT) | 1502mm |
| HEIGHT (DISCHARGE CHUTE UP) | 2545mm |
| WEIGHT | 749 kg |
| SOUND POWER LWA | 117 dB(A) |
| SOUND PRESSURE LPA | 93 dB(A) |
