KGD 1050 EH SA
This Königswieser professional radio cable winch delivers electro-hydraulic operation, maximum stability and a powerful 10.5-tonne pulling force for heavy-duty timber work. The brake holding force helps prevent rope overrun, while the hydraulically actuated self-adjusting 3-disc clutch (via ring cylinder) provides dependable overload protection during demanding pulls.
As standard, it features an infinitely adjustable cable inlet brake and automatic cable ejection to prevent the drum from rolling and keep control consistent on site. Extra stability comes from steel-strut lattice bracing, a counter-mounted rope inlet and a reinforced frame, backed up by a reinforced duplex drive chain for maximum power transmission.
Supplied with hydraulic self-supply, self-adjusting 3-disc clutch, reduction gear, lower rope inlet, trailer clutch, dead man’s brake, protective grille and support feet. Safety precautions in accordance with ÖNORM L 5276, built to CE regulations, supplied with a declaration of conformity.
-
10.5-tonne pulling force with electro-hydraulic operation for professional forestry work
-
Self-adjusting 3-disc clutch with ring cylinder actuation and overload protection
-
Infinitely adjustable cable inlet brake + automatic cable ejection to prevent drum roll and improve control
-
Maximum stability and power transfer via reinforced frame, steel-strut bracing and duplex drive chain
Technical Specifications
|
Tractive power below |
10.5 to |
|---|---|
|
Tractive power top |
5.8 to |
|
Medium rope speed |
0.6 m/s |
|
Max. Rope socket |
|
|
Ø 8 mm |
340 m |
|
Ø 9 mm |
260 m |
|
Ø 10 mm |
220 m |
|
Ø 11 mm |
170 m |
|
Ø 12 mm |
140 m |
|
Ø 13 mm |
120 m |
|
Automatic rope ejection |
Standard |
|
Weight without rope |
776 kg / 796 kg |
|
Total height |
2’300 mm |
|
Cultivation category |
III |
|
Recommended tractor power |
ab 95 PS |
