BMFM-540
The BMF540 is a compact, sturdy forestry crane built for reliable performance across a wide range of tasks. With a single telescope extending the boom, it delivers a total reach of up to 5.4 metres, giving you strong capability without needing a large setup.
It includes a wide-angle linkage system and a three-point connection (with support leg) for stable, controlled handling. Like all BMF cranes, it’s thoroughly tested and designed for long service life, with protected hydraulics, durable turning house and column, a powder-coated finish, and easy-access greasing points. The boom is made from SSAB Strenx steel and carries the My Inner Strenx® mark. Compatible with BMF6T2 and BMF7T1 trailers, and customisable with a wide range of accessories.
-
Up to 5.4 m reach with single telescope boom
-
Wide-angle linkage + three-point connection with support leg
-
Durable build: powder-coated finish, robust turning house/column, easy greasing points
-
Boom made from SSAB Strenx steel (My Inner Strenx®) + compatible with BMF6T2 and BMF7T1 trailers
Technical Specifications
| Maximum Reach, m | 5,4 |
| Lifting Torque, kNm, gross | 30 |
| Lifting power at 4m w/o grapple and rotator, kg | 550 |
| Lifting power at full reach w/o grapple and rotator, kg | 390 |
| Grapple, m2 | 0,15 |
| Rotator, t | 3 |
| Slewing torque, kNm | 4,9 |
| Boom Rotation ° | 360 |
| Working Pressure, bar | 200 |
| Hydr. pump capacity, l/min | 30-60 |
